Siemens SIREMOBIL Iso-C 3D User Manual

Kapitelüberschrift hier eintragen 4 - 11
Siemens AG SPR2-230.814.01 Page 11 of 14 SIREMOBIL Iso-C 3D
Medical Solutions Rev. 05 08.04 CS PS 24
Additional work with the LITHOSTAR MODULARIS option 4
Checking the existing configuration 4
• If the connector of the LITHOSTAR MODULARIS interface cable is already installed into
the mounting location (1/Fig. 24):
- Plug the Y cable, connector D30.X11, into D30.X11.
- Plug the 2nd cable end with connector D200.X211 into D200.X211.
- Skip the following section "Installing the new LITHOSTAR MODULARIS interface" and
continue on page 5-1.
Fig. 24
1
