Simplex 4100ES-S1 Programming Guide

Document: LT0400 4100ES-S1 Programming Guide
Appendices
12-23
P484
INSTALL MODE ACTIVE
TROUBLE
The master will activate this trouble point whenever a point is in Install Mode.
This trouble will clear when there are no points in Install Mode.
P480
COMPACT FLASH MISSING/ FAILED
TROUBLE
The master will activate this trouble point whenever the compact flash is removed, or
is full or cannot be read.
Fitting a new compact flash in the CPU will clear this trouble.
P499
FIRMWARE NEEDS UPDATE
TROUBLE
The master will activate this trouble point whenever there is an incompatible Firmware
version or corrupted .BIN file.
Reload the firmware with the IP File Transfer utility using the Download config and
all execs option. Or use the History/Undo tab to restore to factory default.
System Lists
Point
Label
L18
GENERAL FIRE ALARM MONITOR ZONES
Stores the number of physical alarm type points connected to the
panel.
L76
VARIABLE SENSITIVITY PHOTO ANALOG SENSOR
Stores the number of TrueAlarm Photo detectors connected to the
panel.
L77
VARIABLE SENSITIVITY ION ANALOG SENSOR
Stores the number of TrueAlarm Ionization detectors connected to
the panel.
L78
ANALOG SENSORS WITH PIEZO
Stores the number of TrueAlarm detectors with Piezo (Sounder)
bases connected to the panel.
L79
ANALOG SENSORS WITH RELAY
Stores the number of TrueAlarm detectors with Relay bases
connected to the panel.
System Analog Pseudo Points
Point
Label
A98
BATTERY TROUBLE COUNTER
Stores the number of times a Battery Fault has been detected
since last reboot.
A99
AC POWER FAIL COUNTER
Stores the number of times a Mains Fail Fault has been
detected since last reboot.
