Adding Expansion Modules
8-5
Select the Point type
Refer to Section 6.2 for Point type options.
Enter a Custom Label into the Custom
Label text box.
The Custom Label is limited to 40
characters. It is recommended that the
first characters be the point address,
followed by the description of the point
location and then lastly the zone
number,
e.g., M1-188 FOYER RECEPTION
DESK ZN01
To continue entering new devices click
the Apply or Next buttons
The devices can then be added to
zones as described in Section 5.2.
