•Selecttheleftsideofthebuttontodecreasethenumericalvalue.Selecttherightside
ofthebuttontoincreasethenumericalvalue.
•Pressandholdtheleft
mousebutton.Movethecursorrighttoincreasethevalue.
Movethecursorlefttodecreasethevalue.
•Spinthescrollwheelineitherdirectiontoincreaseordecreasethenumericalvalue.
•Typeanumericalvalue.(Youcanonlytypeanewvalueifacomputerkeyboardis
connectedtoyourSU90ProcessorUnit.)
•Selectthebuttontoopenthebuttonmenu.Choosetherequiredsetting.
•Selectthebuttontoopenthedialogbox.
Choosingasettingwiththe[+]and[–]buttons
1Tochangethesetting,movethecursortoeither
sideofthebutton.
2Observethatthebackgroundcolourchanges.
aSelecttheleftsideofthebuttontodecreasethenumericalvalue.
bSelecttherightsideofthebuttontoincreasethenumericalvalue.
Choosingasettingbymovingthecursor
horizontally
1Placethecursoronthebutton.
2Pressandholdtheleft
mousebutton.
3Movethecursorhorizontallyoverthebutton.
aMovethecursorrighttoincreasethevalue.
bMovethecursorlefttodecreasethevalue.
4Releasethemousebuttonwhenrequestedvalueisshown.
Choosinganumericalsettingwiththescrollwheel
1Placethecursoronthebutton.
2Spinthescrollwheelineitherdirectiontoincreaseordecreasethenumericalvalue.
3Releasethescrollwheelwhentherequestedvalueisshown.
Choosingasettingwiththekeyboard
1Placethecursoronthebutton.
2Clickthebuttontoopenthetexteld.
3Typeanumericalvalue.
Ifthevalueexceedsthepermittedrange,theframeturnsred.Typeanewvalue
withintheacceptedrange.
4PressEnteronthekeyboard.
