EA180 Servo Drive Manual
41
from enabled ON to enabled OFF.
d0-22
IGBT module temperature
Initial value
0
Commu.addr.
2016H
Unit
Type
Display
Range
0~150
Format
Decimal
Data size
16bit
Control mode
P S T
Internal temperature of IGBT module
This drive has a perfect over temperature protection mechanism. Because of the temperature detection position, the temperature may
be 100 degrees or higher, which is normal.
d0-24
Total elapsed time of the system
Initial value
0
Commu.addr.
2018H
Unit
Min
Type
Display
Range
0~2147483647
Format
Decimal
Data size
32bit
Control mode
P S T
Display the elapsed running time in enabled ON state (to prevent EEPROM damage, this parameter is saved every 10 minutes)
d0-26
Brake load rate
Initial value
0.0
Commu.addr.
201AH
Unit
%
Type
Display
Range
0.0~400.0
Format
Decimal
Data size
16bit
Control mode
P S T
When the motor is in a braking state, the load rate of the current braking resistance is displayed.




d0-27
Current motor electrical angle
Initial value
By motor
Commu.addr.
201BH
Unit
°
Type
Display
Range
0.0~359.9
Format
Decimal
Data size
16bit
Control mode
P S T
Show the current angle of the motor rotor.
Electrical angle = motor mechanical angle * motor pole count
d0-28
Incremental encoder sector number
Initial value
0
Commu.addr.
201CH
Unit
-
Type
Display
Range
0~7
Format
Decimal
Data size
16bit
Control mode
P S T
Display the current sector code of the incremental encoder. 0 or 7 indicates that the encoder is out of order
If the motor is used with a 2500ppr incremental encoder, the sector number means the UVW combination of the encoder feedback, and
generally when rotating counterclockwise, it jumps according to 1- > 5- > 4- > 6- > 2- > 3-.
d0-29
Revolutions number of absolute encoder
Initial value
0
Commu.addr.
201DH
Unit
Rev
Type
Display
Range
-32768~+32767
Format
Decimal
Data size
16bit
Control mode
P S T
Display the multi-circle value of absolute encoder, - sign means the opposite direction(the actual motor direction defined by P0-01)
d0-30
Serial encoder current turn position value
Initial value
0
Commu.addr.
201EH
Unit
Pulse
Type
Display
Range
0~8388608
Format
Decimal
Data size
32bit
Control mode
P S T
Display the current single-circle position value of the serial encoder feedback.
d0-32
The total number of external pulses gathered
Initial value
0
Commu.addr.
2020H
Unit
Pulse
Type
Display
Range
-2147483647~2147483647
Format
Decimal
Data size
32bit
Control mode
P
In position mode, the total number of pulses sent to the servo drive by the host computer, useful only in the position control mode.
1: this value has not been processed by the frequency doubling of the electronic gear, which is the actual number of external pulses
received.
2: this value may be greater than five bits. Please use the shift key to view high data.
3: continuous positive direction pulse, this value is positive increase, when the direction of the command changes to reverse, the
value continues to decrease, after zero, negative increase.
4: if the received pulse exceeds the range above, it will start counting again from the maximum value in the opposite direction.
5: the value of this parameter starts when the servo drive is powered on, and automatically reset when the drive is powered down.
d0-34
Servo motor current position (command pulse unit)
Initial value
0
Commu.addr.
2022H
Unit
Pulse
Type
Display
Range
-2147483647~2147483647
Format
Decimal
Data size
32bit
Control mode
P S T
The total pulse number of the servo motor based on the command pulse is shown, valid in any mode.
1: this value is the encoder feedback pulse, it obtains the corresponding command pulse number after the electronic gear ratio
reverse processing.
2: this value may be greater than five bits. Please use the shift key to view high data.
3: the motor continues to rotate in a positive direction, this value is increasing, and when the rotation direction of the motor becomes
reverse, the value will continue to decrease, and it will increase negatively after zero.
4: if the number of feedback pulses is greater than the range above, the count starts at the opposite direction.
