MN.00356.E - 003 111
Section 7.
COMPOSITION
16 COMPOSITION OF OUTDOOR UNIT
16.1 GENERAL
There are several versions of ALFOplus2, each of them with different hardware characteristics. If one of
these is inserted improperly in local and remote side, radio link doesn’t work.
Following statements:
• the ODU must be assembled with proper antenna adapter module. See Tab.18
for the code relevant
frequency and characteristics.
• you must have 2 ODUs, the first working in the lower selected subband and the second one working
in the correspondent higher subband; e.g. 1L-1H, 2H-2L, etc....
Unit part number, hardware layout and equipment composition are subject to change without notice.
16.2 ODU PART NUMBER
Every version is identified by a specific part number shown on a label attached on ODU.
Other information such as power consumption, allowed configuration, feature key, system version, part
number P/N and serial number S/N are also written.
Tab.17 - ALFOplus2 versions
Code Description Go-Return [MHz] RF Subband
GC8606 ODU ALFOplus2 11 E/O 490/530/500 11GHz 1L
GC8607 ODU ALFOplus2 11 E/O 490/530/500 11GHz 1H
GC8608 ODU ALFOplus2 11 E/O 490/530 11GHz 2L
