36 MN.00356.E - 003
6.4 POWER SUPPLY AND CABLE
Power supply can be provided at the 48V port and at the electrical Ethernet ports (in case of PoE).
- Operating voltage range -37Vdc (38Vdc in case of PoE)/Vin/ -60Vdc
(floating input)
- Circuit breaker 6A type C
- P.E max current limit 850mA (per one pair)
- Power consumption 8 see Tab.7
-Cable max length see Tab.8
- Power cable operating temp. 60°C
Tab.7 - ALFOplus2 power consumption
Tab.8 - Cable max length
6.5 PHYSICAL DIMENSIONS
ALFOplus2 physical dimensions include Hybrid or OMT module. See Fig.16:
- wxhxd 252mm x 363mm x 148mm (frequency 15GHz)
252mm x 363mm x 176mm (frequency < 15 GHz)
- Unit Weight 8Kg (frequency 15GHz)
11.5Kg (frequency < 11GHz)
RF Guaranteed (W) Typical (W) Typical @ Min power (ATPC) (W)
11 GHz HP 90 80 72
RF 15 GHz 70 60 54
90W equipment
Battery supply voltage
(40.5 Vdc)
Battery supply voltage
(46 Vdc)
M10154 (0.75mmq) 25.00 50.00
M10166 (1.5mmq) 50.00 100.00
M10184 (2.5mmq)
a
a. An adapter is required
80.00 200.00
70W equipment
Battery supply voltage
(40.5 Vdc)
Battery supply voltage
(46 Vdc)
M10154 (0.75mmq) 30.00 80.00
M10166 (1.5mmq) 60.00 150.00
M10184 (2.5mmq)
a.
100.00 250.00
