SM ALFOplus2 - Radio Flange; Power Supply and Consumption

140 MN.00356.E - 003
- Rx Spurious emissions according to ETSI EN 301 390
- AGC dynamic range from -21 dBm to Threshold @ BER=10
-6
- Accuracy of Rx level indication @ 25 C° (PC reading)±2dB in the range -22dBm ÷ Thresholds @
BER=10
-6
- Accuracy of Rx level indication over the
whole temperature range (PC reading) ±3dB in the range -50dBm ÷ Thresholds @
BER=10
-6
±4dB in the range -49dBm ÷ -22dBm
- Maximum input level for BER 10
-6
-21 dBm for modulations below 64QAM
-22 dBm for modulations equal or higher than
64QAM
- Residual BER (RBER) 10
-12
20.3 RADIO FLANGE
- Radio WG flange type UBR 220 (ODU configuration with hybrid and
flange kit)
UBR 220 (ODU configuration Dual Flange and
flange kit)
C 220 (ODU configuration with OMT)
20.4 POWER SUPPLY AND CONSUMPTION
- Operating voltage range -37.5 ÷ -60Vdc
- PoE operating voltage range -38.5 ÷ -60Vdc
-Power consumption see Tab.56
Tab.50 - Power consumption
56
BER=10
-6
-66.0 -62.5 -59.5 -56.0 -54.5 -51.0
BER=10
-10
-64.0 -60.5 -57.5 -54.0 -52.5 -49.0
112
BER=10
-6
-63.0 -60.0 -57.0 -53.5 -51.5 -48.0
BER=10
-10
-61.0 -58.0 -55.0 -51.5 -49.5 -46.0
Typical power consumption (W) Guaranteed power consumption (W)
60.0  70.0
