SM ALFOplus2 - Single Alfoplus2; Dual Alfoplus2

18 MN.00356.E - 003
5.5.1 Single ALFOplus2
Single ALFOplus2 RF-Dual core solution allows the following configurations (See Tab.2):
• 1+0 unprotected (with second core not enabled)
• 2+0 CP (Co-polar)
• 2+0 AP (Alternate Polarization)
• 2+0 XPIC (Cross Polar Interference Cancellers).
Tab.2 - Single ALFOplus2 configurations (purpose, interface module, used antenna)
5.5.2 Dual ALFOplus2
Two ALFOplus2 RF-Dual core solutions allows the following configurations (see Tab.3 and Tab.4):
• 2+2 CP Protected (HSTBY or FD)
• 2+2 AP Protected (HSTBY or FD)
• 2+2 XPIC (HSTBY or FD)
• 4+0 CP unprotected
•4+0 AP unprotected
• 4+0 XPIC unprotected.
Tab.3 - Dual ALFOplus2 in 2+0 configurations (purpose, interface module, used antenna)
Single ALFOplus2
Interface
module
Antenna type
Radio
configurations
Circular
waveguide
Single waveguide Dual waveguide
Integrated Integrated Not integrated External
OMT
Dual flange
Hybrid X X
OMT X
Dual flange X
Hybrid
OMT X
Dual flange X
Hybrid
Dual ALFOplus2
2+0 operations
Interface
module
Antenna type
Radio
configurations
Circular
waveguide
Single waveguide
Dual
waveguide
Integrated Integrated Not integrated External
2+2 CP
HSBY or protected SW
OMT
2 ports
Hybrid
X
