SM ALFOplus2 - ALFOplus2 25 GHz Characteristics

MN.00356.E - 003 139
20.2.2 Receiver characteristics
- Receiver bandwidth See Tab.52
- Noise Figure 7.5 dB
- Guaranteed receiver sensitivities (dBm) see Tab.55
- Typical receiver sensitivities (dBm) 2dB better (lower) than guaranteed receiver
sensitivities
Tab.49 - Sensitivity (guaranteed values)
CHANNEL BANDWIDTH [MHz] 4QAMs 4QAM 16QAMs 16QAM 32QAM 64QAM
14
BER=10
-6
-88.5 -87.0 -82.5 -81.5 -78.0 -74.5
BER=10
-10
-86.5 -85.0 -80.5 -79.5 -76.0 -72.5
20
BER=10
-6
-87.0 -85.5 -81.5 -80.0 -76.5 -73.5
BER=10
-10
-85.0 -83.5 -79.5 -78.0 -74.5 -71.5
28
BER=10
-6
-85.5 -84.0 -79.5 -78.5 -74.5 -71.5
BER=10
-10
-83.5 -82.0 -77.5 -76.5 -72.5 -69.5
30
BER=10
-6
-85.5 -84.0 -79.5 -78.0 -74.5 -71.5
BER=10
-10
-83.5 -82.0 -77.5 -76.0 -72.5 -69.5
40
BER=10
-6
-84.5 -82.5 -78.0 -77.0 -73.5 -71.0
BER=10
-10
-82.5 -80.5 -76.0 -75.0 -71.5 -69.0
50
BER=10
-6
-83.5 -81.5 -77.0 -76.0 -72.5 -70.0
BER=10
-10
-81.5 -79.5 -75.0 -74.0 -70.5 -68.0
56
BER=10
-6
-82.5 -81.0 -77.0 -75.5 -72.5 -69.5
BER=10
-10
-80.5 -79.0 -75.0 -73.5 -70.5 -67.5
112
BER=10
-6
-79.5 -78.0 -73.5 -72.5 -69.0 -66.5
BER=10
-10
-77.5 -76.0 -71.5 -70.5 -67.0 -64.5
CHANNEL BANDWIDTH [MHz] 128QAM 256QAM 512QAM 1024QAM 2048QAM 4096QAM
14
BER=10
-6
-71.0 -68.0 -64.5 -61.5 -59.0 -
BER=10
-10
-69.0 -66.0 -62.5 -59.5 -57.0 -
20
BER=10
-6
-70.0 -66.5 -63.5 -60.0 -58.0 -
BER=10
-10
-68.0 -64.5 -61.5 -58.0 -56.0 -
28
BER=10
-6
-68.0 -65.0 -61.5 -58.0 -56.5 -53.0
BER=10
-10
-66.0 -63.0 -59.5 -56.0 -54.5 -51.0
30
BER=10
-6
-68.0 -65.0 -61.5 -58.0 -56.0 -52.5
BER=10
-10
-66.0 -63.0 -59.5 -56.0 -54.0 -50.5
40
BER=10
-6
-67.0 -64.5 -61.0 -57.0 -55.5 -52.0
BER=10
-10
-65.0 -62.5 -59.0 -55.0 -53.5 -50.0
50
BER=10
-6
-66.5 -63.5 -60.0 -56.5 -55.0 -51.5
BER=10
-10
-64.5 -61.5 -58.0 -54.5 -53.0 -49.5
