Paramount ME User’s Guide

Mount Nomenclature

Counterweights

Counterweight attachment block

Pier

Baseplate attachment

knobs (4) with Micro-levelers

underneath (4)

Altitude positioning

device

Altitude retaining knobs

(2 each side)

Azimuth adjustment knobs (2)

Declination assembly

RA assembly

Wedge assembly

Declination motor cover

Telescope plate

Counterweight shaft

Figure 2: Paramount ME components.

Versa-Plate
