breakersonthedistributionpanel.Wait5minutesforthecapacitorstodischarge.
4.
Opentheinvertercover’ssixAllenscrewsandcarefullypullthecoverhorizontallybeforeloweringit.
CAUTION!
When removing the cover, make sure not to damage internal components. SolarEdge will not
be held responsible for any components damaged as a result of incautious cover removal.
Lors du retrait du couvercle, assurez-vous de ne pas endommager les composants internes.
SolarEdge ne peut être tenue pour responsable des composants endommagés à la suite
d'une imprudence dans le retrait du couvercle.
Inverter Configuration – Setup Mode
Youcanconfiguretheinverterusingoneofthefollowing:
l TheinternalLCDuserbuttons.Whenusingthisoption,theinvertercoverisremoved.
l TheexternalLCDlightbutton.Thisoptionofconfigurationincludesalessdetailedconfiguration
menu.
Configuring the Inverter Using the LCD User Buttons
Afterinverterinstallation,afieldtechnicianmayperformbasicsystemconfiguration.Configurationis
donewhentheinverterisinSetupmode.
To enter Setup mode:
1.
TurntheinverterON/OFFswitchtoOFF(ACremainsON).
WARNING!
If the inverter was operating properly (power was produced by the power optimizers), the
following message is displayed.
D C V O L T A G E N O T S A F E
D O N O T D I S C O N N E C T V D C : 7 2 . 0
This message is displayed until the DC voltage is safe (50V). Do not open the cover until the
voltage is safe or until at least five minutes have passed.
La tension de sécurité par défault est de 50V.
Ne pas ouvrir le couvercle ou les connecteurs DC jusqu'à ce que la tension soit affichée comme
sécurisé ou jusqu'à ce que cinq minutes au moins se soient écoulées.
2. PresstheEnterbuttonforatleast5seconds.Thefollowingmessageisdisplayed:
P l e a s e e n t e r
P a s s w o r d
* * * * * * * *
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.0
40
Inverter Configuration – Setup Mode
