l RSSI:ThereceivesignalstrengthindicationoftheclosestZigBeeinthesystem.L=low,M=medium,H
=highand
(-)=nosignal.
l PAN ID:TheZigBeetransceiverPANID
l Ch.:TheZigBeetransceiverchannel
l ID:TheZigBeetransceiverID
l MID:TheMasterIDofthecoordinator(master)ZigBeemodule.Thisfieldisshownonlyindeviceswith
router(slave)ZigBeemodules,andafterasuccessfulZigBeeassociation.IfaZigBeemoduleisnot
connected,aNo ZigBeemessageisdisplayedinsteadoftheMID field.
Cellular Status
Ifacellular(CDMA)modemisconnected,thisscreenreplacestheServerstatusscreen:
S e r v e r : C e l l < S _ O K >
S t a t u s : < O K > S i g : 5
< E r r o r m e s s a g e >
l Server:ThemethodofcommunicationtotheSolarEdgemonitoringportal.ShoulddisplayCell.
l Status:DisplaysOKiftheinverterestablishedasuccessfulphysicalconnectiontotheCellularmodem.
l S_OK:ThelastcommunicationtotheSolarEdgemonitoringportalwassuccessful(appearsifthe
inverterisconnectedtotheportal).
l Sig:Thesignalstrength,receivedfromthecellularmodem.Avaluebetween0-5,(0=nosignal,5=
excellentsignal).
l Error messagepercommunicationconnectionstatusfailure
GSMStatus
IfaGSMmodemisconnected,thisscreenreplacestheServerstatusscreen:
S e r v e r : C e l l < S _ O K >
S t a t u s : < O K >
M N O : < x x x x x x x > S i g : 5
< E r r o r m e s s a g e >
l Server:ThemethodofcommunicationtotheSolarEdgemonitoringportal.ShoulddisplayCell.
l Status:DisplaysOKiftheinverterestablishedasuccessfulphysicalconnectiontothemodem.
l S_OK:ThelastcommunicationtotheSolarEdgemonitoringportalwassuccessful(appearsifthe
inverterisconnectedtotheportal).IfS_OKisnotdisplayed,refertoStatusScreens-OperationalMode
onpage49.
l MNO:Themobilenetworkoperatorname
l Sig:Thesignalstrength,receivedfromthemodem.Avaluebetween0-5,(0=nosignal,5=excellent
signal).
l Error messagepercommunicationconnectionstatusfailure.
Communication Ports Status
D e v P r o t # #
R S 4 8 5 - 1 < S E > < S > < - - >
Z i g B e e < S E > < M P S > < - - >
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.0
52
