SolarEdge StorEdge SE7600A-USS Installation Guide

Configuring StorEdge Application
ThissectiondescribestheStorEdgeapplicationsandhowtoconfigurethesystemperapplication.
Maximize Self-consumption
Inthismode,thebatteryisautomaticallychargedanddischargedtomeetconsumptionneeds.This
applicationrequiresconnectiontoameter.
Thebatteryhastwostates:
l OFF–thebatteryisinstandby
l ON–thebatteryiscontrolledformaximizedself-consumption
BatteryOFFperiodscanbeconfiguredtoextendbatterylifetimebyminimizingthenumberofshallow
discharges(forexampleatnighttimeorduringthewinter).
Profile Programming (for time of use arbitrage)
Inthismode,theStorEdgesystemoperatesaccordingtoaconfiguredcharge/dischargeprofile.This
applicationrequiresconnectiontoameter.Thisapplicationiscoveredinaseparateapplicationnote
availableathttp://www.solaredge.com/files/pdfs/StorEdge_TOU_profile_programming.pdf.
ThisapplicationcanbeusedwhetherornotPVmodulesareinstalledatthesite.
Backup Power
Theproducedpowerisstoredinthebatterytobeusedduringpoweroutages.TheStorEdgeinverter
sensesthegridvoltage,andwhenitisdownitautomaticallyswitchestoBackupmode,disconnecting
fromthegridandsupplyingpowertothebacked-uploads.Thisapplicationrequiresconnectiontothe
SolarEdgeAuto-transformerandabacked-uploadspanel.
Thisapplicationcanbeusedinoneoftwoways:
l Backup-only–energystoredinthebatteryisdischargedforbackuppoweronly
l Backup with Smart Energy Management–usesomeofthebatteryenergyforbackuppowerandthe
restforMSCorTOUapplications.
TheBackupapplicationcanbeusedwhetherornotPVmodulesareinstalledatthesite.
System Configuration
To access the Energy Control menu:
1.
EnterSetupmode,scrolldowntothe Power Control menuandselectit.Amenusimilartothe
followingisdisplayed:
G r i d C o n t r o l < E n >
E n e r g y M a n a g e r
R R C R C o n f .
R e a c t i v e P w r C o n f .
A c t i v e P w r C o n f .
P h a s e B a l a n c e < D i s >
W a k e u p C o n f .
P ( f )
A d v a n c e d
L o a d D e f a u l t s
Chapter 9: System Configuration
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.0
65
