SolarEdge StorEdge SE7600A-USS Installation Guide

Mounting the Inverter
NOTE
Make sure the mounting surface or structure can support the weight of the inverter , and make sure
that it spans the width of the bracket.
CAUTION!
HEAVY OBJECT. To avoid muscle strain or back injury, use proper lifting techniques, and if required
- a lifting aid when removing or replacing.
Objet lourd. Pour éviter la fatigue musculaire ou des blessures au dos, utilisez des techniques de
levage appropriées et, si nécessaire - un auxiliaire de levage lors du retrait ou du remplacement.
1. Determinetheinvertermountinglocation,onawall,studframingorpole.Toallowproperheat
dissipation,maintainthefollowingminimumclearanceareasbetweentheinverterandotherobjects:
l Ifinstallingasingleinverter:

o
8"(20cm)tothetopoftheinverter.

o
Atleast8"(20cm)tothebottomoftheStorEdgeConnectionUnit;ifconduitentrytothe
StorEdgeConnectionUnitwillbefromthebottom,leavesufficientclearancefortheconduitsas
well.

o
4"(10cm)totherightandleftoftheinverter.
l Ifinstallingmultipleinverters:

o
Wheninstallinginvertersoneabovetheother,leaveatleast8"(20cm)betweenthetopofan
inverterandthebottomofaStorEdgeConnectionUnit.

o
Wheninstallinginverterssidebyside,leave20cm/8"betweeninverters.
2. Positionthemountingbracketagainstthewall/poleandmarkthedrillingholelocations:

o
Ensurethattheflatsideofthebracketisatthebottom,asinFigure12.

o
Useatleasttwobracketholes.Additionalholescanbeusedtofixthebracket.Determinewhich
andhowmanyholestouseaccordingtomountingsurfacetypeandmaterial.
3. Drilltheholesandmountthebracket.Verifythatthebracketisfirmlyattachedtothemounting
surface.
NOTE
When mounting an inverter on an uneven surface, you may use spacers/ washers behind the top
mounting hole of the bracket (see ). Depending on the angle, use the appropriate size and number of
spacers so that the bracket is perpendicular to the ground. Recommended: a stainless steel 3/4" long
screw, with a 1/4" socket button head , two jam nuts and three washers.
4. Hangtheinverteronthebracket(seeFigure12):Lifttheinverterfromthesides,orholditatthetop
andbottomoftheinvertertolifttheunitintoplace.DonotliftholdingtheSafetySwitchStorEdge
ConnectionUnitasitmaybedamaged.
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.0
22
Mounting the Inverter
