Energy Meter Status
Displaysthetotalenergyproducedduringthelastday,month,yearandsinceinverterinstallation.
D a y [ W h ] : 0 . 0
M o n t h [ K W h ] : 0 . 0
Y e a r [ K W h ] : 0 . 0
T o t a l [ K W h ] : 0 . 0
Ifameterisconnectedtotheinverter,thefollowingstatusscreen,showingthetotalenergyreading,is
displayedinsteadoftheabovescreen.Thefollowingisanexampleofaproductionmeterstatus:
P r o d u c t i o n M e t e r
S t a t u s : < O K >
< E r r o r M e s s a g e >
T o t a l [ W h ] : X X X X X X X
IfthemeterissettoExport+Import,therearetwostatusscreens,withthefirstlinedisplaying:
"ExportMeter"and"ImportMeter".
l Status:DisplaysOKifthemeteriscommunicatingwiththecommunicationboard.
l <Error message>:Ifthereisametererror,itisdisplayedinthisline.
l Total (Wh):Theenergyreadbythemeter.Thevaluedisplayedinthislinedependsonthemetertype
connectedtotheinverteranditslocation:
o
Ifabidirectionalmeterisconnectedattheconsumptionpoint,thisvalueistheconsumedenergy.
o
Ifthemeterisinstalledattheproductionconnectionpoint,thisvalueistheenergyproducedby
thesite.
o
Ifthemeterisinstalledatthegridconnectionpoint,thisvalueistheenergyexportedtothegrid.
IftheinverterisconnectedtotheSolarEdgeserver,thisvaluewillalsobedisplayedinthemonitoring
portal.
NOTE
This data is accumulated according to an internal real-time clock.
Telemetry Status
Thisscreendisplaysthelastpoweroptimizertelemetryreceived.Thedisplaychangesaseachpower
optimizersendsitstelemetry.
Inordertoverifyproperinstallation,theinstallermayviewtheTelemetrywindowforsometimeinorder
toobservethepoweroptimizers'reportprocess.
M o d u l e : 0 0 0 C 1 E D 9 - 0 3
E n e r g y [ W h ] : 0
V d c _ O [ V ] : 0 . 5
V d c _ I [ V ] : 2 9 . 5
l Module#:Poweroptimizerserialnumber
l Energy:poweroptimizerenergy
l Vdc_O:Poweroptimizeroutputvoltage
l Vdc_I:Poweroptimizerinputvoltage(modulevoltage)
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.0
