Configuring the Inverter Using the LCD Light Button
UsetheLCDlightbuttonforcommunicationsetupandfordisplayingtheErrorlogandWarningLog.
Therearefewermenusavailablewhenusingthisconfigurationoption;however,thefunctionalityof
thesemenusisthesameaswhenusingtheinternalLCDuserbuttons.
1. TurntheinverterON/OFFswitchtoOFF.
2.
PressandholddowntheLCDlightbuttonuntilthefollowingmessageisdisplayed:
K e e p h o l d i n g b u t t o n
f o r p a i r i n g , r e l e a s e
t o e n t e r m e n u . . .
R e m a i n i n g : 3 s e c
Releasingthebuttondisplaysthefollowingmenu:
O p t i m i z e r p a i r i n g
L a n g u a g e < e n g >
C o m m u n i c a t i o n
M a i n t e n a n c e
I n f o r m a t i o n
E x i t
3. Short-press(onesecond)toscrolldowntothenextmenuoption,andlong-press(threeseconds)to
selecttheitem.YoucanusetheExit optioninthesemenustomoveuponemenulevelortoexitthe
Setupmodefromthemainmenu.
ThefollowingshowsahierarchicaltreeofthemenuoptionsthatappearwhenusingtheLCDlightbutton:
Mainmenu:
O p t i m i z e r p a i r i n g
L a n g u a g e < e n g >
C o m m u n i c a t i o n
M a i n t e n a n c e
I n f o r m a t i o n
E x i t
Language:
E n g l i s h
G e r m a n
S p a n i s h
F r e n c h
I t a l i a n
E x i t

