๎l PWR Limit:๎The๎inverter๎maximum๎output๎power๎set๎by๎one๎of๎the๎power๎limiting๎options:๎
๎
o
RRCR๎
๎
o
Smart๎energy๎manager๎(Feed-in๎limitation)๎
๎
o
P(f)
๎
o
Q(U)๎
๎l Cos Phi:๎The๎ratio๎between๎active๎to๎reactive๎power๎
๎l Power Prod:๎The๎power๎produced๎by๎the๎inverter๎
For๎more๎information,๎refer๎to๎the๎following๎application๎notes:๎
๎
o
Power๎Control๎Application๎Note,๎available๎on๎the๎SolarEdge๎website๎at๎
http://www.solaredge.us/files/pdfs/application_note_power_control_configuration.pdf
๎
o
Feed-in๎Limitation๎Application๎Note,๎available๎on๎the๎SolarEdge๎website๎at๎
http://www.solaredge.us/files/pdfs/products/feed-in_limitation_application_note.pdf
Battery Status
This๎screen๎is๎displayed๎only๎when๎the๎battery๎is๎configured,๎and๎shows๎the๎battery๎identification๎
information,๎its๎charging๎status๎and๎power,๎and๎the๎operating๎mode.
B S N : X X X X X X X X X I D : 2 4
S O E : 8 9 % W W W W W P W R : 0 W
T o t a l : 0 W h
S t a t e : I d l e
๎l BSN:๎Battery๎serial๎number
๎l ID:๎Battery๎identification๎-๎should๎be๎24๎as๎set๎up๎above
๎l SOE:๎State๎of๎Energy๎-๎the๎battery๎capacity๎percentage๎(calculated๎as๎Available๎Energy\Max.๎Energy)
๎l PWR:๎The๎charging๎or๎discharging๎power๎(in๎Watts)๎according๎to๎the๎battery๎state๎(see๎below)
๎l Total:๎The๎total๎discharged๎energy๎in๎Watt/hour
๎l State:๎The๎battery๎status:๎Charging/๎Discharging,๎Idle,๎Init๎(pre-heating)๎or๎Fault๎<error๎code>.
Time Of Use Status
This๎screen๎is๎sisplayed๎only๎if๎TOU๎is๎configured,๎and๎shows๎information๎about๎the๎TOU๎settings๎for๎the๎
site.
N a m e : x x x x
L a s t S y n c : < D a t e >
S o u r c e : < R e m o t e >
S e t U n t i l : < d a t e >
๎l Name:๎The๎TOU๎profile๎file๎name๎
๎l Last Sync:๎Date๎when๎the๎time-of-use๎profile๎was๎loaded๎from๎the๎monitoring๎portal
๎l Source:๎the๎source๎from๎which๎the๎TOU๎profile๎was๎uploade:๎
๎
o
Remote๎-๎Profile๎uploaded๎from๎the๎SolarEdge๎monitoring๎portal
๎
o
Local๎-๎Profile๎uploaded๎from๎an๎SD๎card
๎l Set Until:๎The๎date๎until๎the๎current๎profileis๎applicable
๎
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.0
54
