149
9 Operation on LCD
9.1 Overview of LCD
Press Up and Down to select the setting item and press Enter to confirm it.
If there is no operation on the inverter's LCD screen for 10 minutes, it will go black. Press
any key to illuminate the screen again.
The main interface is the default interface, the inverter will automatically return to this
interface when the system starts successfully or does not operate for a period of time.
The information of the main interface is as below. Power means the current output power
of the inverter; Today means daily generated power of the inverterl; Battery means the left
capacity of the battery.
Power xx W
Today xx kWh
Battery xx %
Normal
Figure 9-1 Information of the main interface
When the inverter is in the default control panel, press Enter to enter the menu interface.
The screen only displays 4 items with the title included. You can press Up or Down to get
full information.
=====Menu=====
History Data
>Settings
About
=====Menu=====
System ON/OFF
>Mode Select
System Status
Figure 9-2 Overview of the menu interface
• “System ON/OFF”
• “Work Mode”
Work Mode
Self Use
Feed-in Priority
Backup Mode
Manual
Peak Shaving
TOU Mode
Figure 9-3 Work mode diagram
