Operation on LCD
»
Meter/CT
Here display the feedin power of each phase of Meter/CT1 and the power of each
phase of Meter2. The third LCD below will display if a Meter2 is connected.
====System Status====
EPS
>Meter/CT
=====Meter/CT=====
>Pfeedin A 0W
Pfeedin B 0W
Pfeedin C 0W
=====Meter/CT=====
>P_USERDEF A 0W
P_USERDEF B 0W
P_USERDEF C 0W
Figure 9-18 Displaying Meter/CT status
9.5 Parallel Status
Displaying path: Menu > Parallel Status
It displays only when X3-IES devices have a parallel connection. X3-IES supports another 9
slave devices connected.
Displaying Parallel Status
Here displays the number of devices and the devices in a parallel status Press
Down and get all slaver inverters.
===Parallel Status===
>All 3
Slaver1
Slaver2
Figure 9-19 Displaying paralleling status
