SolaX Power X3-IES Series - Two Towers for Wall Mounting

83
Mechanical Installation
6.3.2 Two Towers for Wall Mounting
NOTICE!
• Take the installation procedure for six battery modules as an example.
Step 1: As for the installation steps for the following figure, please refer to the installation
procedure for “6.3.1 One Tower for Wall Mounting” (Steps 1 to 17). The installation
procedure for both left and right towers is the same.
Figure 6-52 Installing two towers
