Product Overview
Item Description
Upgrade/ Dongle
USB port for upgrading and communication module connection.
Communication module includes a dongle/ 4G (optional) .
DC switch Disconnect the PV input when necessary.
Button Power on or off the inverter system.
Inverter electrical
connection area
Including PV terminals, battery terminals, AC terminals,
communication terminals, etc.
Battery electrical
connection area
Including B+/B- ports, communication port, heat port, grounding
port. Please refer to “Figure 2-5 BMS” for details.
2.3.1 Dimensions
Inverter Dimensions
717 mm
405 mm
209.5 mm
Figure 2-6 Inverter
Battery Dimensions
B+
B-
HEATCOM
165 mm
730 mm
150 mm
Figure 2-7 BMS

SolaX Power X3-IES Series Specifications

General

Brand	SolaX Power
Model	X3-IES Series
Category	Inverter
Language	English
