45
Preparation before Installation
4.1.4 Clearance Requirement
To guarantee proper heat dissipation and ease of disassembly, the minimum space around
the inverter must meet the standards indicated below.
• For installations with multiple devices, make sure to leave a minimum space of
300 mm between the left and right tower and 300 mm from the ceiling.
• If wall mounting is selected, the distance between the base support and the
ground is decided by the corresponding requirement of the local regulations. For
safety, it is suggested the base support be installed as low as possible.
• In areas with high ambient temperatures, increase the clearances between the
devices and provide adequate fresh air ventilation if feasible.
Single tower
Two towers
>300 mm
>300 mm
>300 mm
>300 mm
>300 mm
>30 cm
>300 mm
>300 mm
>300 mm
Figure 4-7 Clearance requirement
