164
Operation on LCD
9.7.2 Advance Setting
Setting path: Menu > Setting > Password > Advance Setting
Only professional installers can modify the items (refer to “Figure 9-7 Advance setting
diagram”) in the Advance Setting interface under the permission of SolaX company.
Setting Safety Code
In order for the inverter to be able to feed in, the safety code must be set as the installation
site correctly. Here you can set safety code according to different countries and grid-tied
standards.
Nine standards are avaiable.(may be changed without notice)
Table 9-1 Standards
Standard Country Standard Country
VDE 0126 German EN 50438_NL Netherland
ARN 4015 German CEI 0-21 Italy
AS 4777 Australia IEC61727_In India
EN 50549_EU Netherland C10/11 Belgium
G98/G99 UK
NOTICE!
• The inverter cannot be connected to the grid before the safety code is correctly set. If
there is any doubt about your safety code where the inverter installed, please consult
your dealer or SolaX service for details.
NOTICE!
• For the Australian, please select Australia Region A/B/C in complicance with AS/
NZS 4777.2:2020. Only after the safety code setting is completed, some designated
parameters in the inverter system will take effect according to the corresponding
safety regulations.
»
Select and enter Safety Code interface. Select the correct safety code.
=====Safety Code=====
>Country:
VDE0126
Figure 9-42 Setting the safety code
»
For the Australian market, select the specific region in compliance with AS/
NZS 4777.2:2020. The default setting for different regions are as follows for
To Next Page
