Product Overview
Item Description
B Grid(INV): Connect to the Grid port of the inverter.
C
Meter/CT: Connect to the Meter/CT port of the inverter when a meter is
selected. Connect to the Meter/CT port of the inverter with CTs connected in
between when CTs are selected.
D Grid: Connect to the power grid.
E Load: Connect to the loads.
2.3.4 Symbols on the Label and Devices of X3-IES System
Table 2-12 Description of symbols
Symbol Description
CE mark.
The inverter complies with the requirementsof the applicable CE
guidelines.
TUV certified.
RCM mark.
The inverter complies with the requirementsof the applicable RCM
guidelines.
Additional grounding point
Beware of hot surface.
The inverter can become hot during operation. Avoid contact during
operatior.
Danger of high voltages.
Danger to life due to high voltages in the inverter!
Danger.
Risk of electric shock!
The battery module may explode.
Keep the battery system away from open flames or ignition systems.
Keep the battery system away from children.
