SolaX Power X3-IES Series User Manual

57
6 Mechanical Installation
6.1 Mechanical Installation of X3-IES System
Figure 6-1 Correct installtion angle
NOTICE!
• The wall selected for installation should be flat and perpendicular to the floor.
The mechanical installation of the X3-IES system supports floor mounting and wall
mounting. The two installation methods are illustrated below. Option B with three battery
modules is taken as an example.
Floor mounting
Wall mounting
Figure 6-2 Installation modes
