177
Operation on LCD
How to remove the parallel connection
c. Select the Parallel Settings, set the master inverter as Free and then set all slave
inverters as Free.
==Parallel Connection==
Setting
> Free <
===Advance Setting===
Battery
>Parallel Setting
Reset
Figure 9-68 Removing parallel connection
d. Disconnect all the network cables on the COM port.
NOTICE!
If a slave inverter is set to Free mode but not disconnect the network cable, this
inverter will return to Slave mode automatically.
If a slave inverter is disconnected with other inverter but not be set to Free mode, this
inverter will stop working and maintain waiting status.
LCD Display after Parallel Connection
Once inverter enters parallel system, the Today yield will be replaced by the
Parallel Status of the inverter, and parallel relevant fault has a higher priority than
other faults and will be showed firstly on main display.
Power 5688W
Parallel Master
Battery 67%
Normal
Power 5688W
Parallel Slave
Battery 67%
Normal
Figure 9-69 Displaying the master and slave inverter data
User can obtain all the status data from master inverter. System power and
individual slave inverter power can be obtained in status display of master inverter.
====Parallel Status====
>All 2
Slaver1
Slaver2
====Parallel Status====
>Grid
Solar
Load
======Menu======
Status
>Parallel Status
History
Figure 9-70 Getting all information from the master inverter
Setting Main Breaker Limit
For the power limit of a smart meter or CT, the current must be set in line with
the utility's contract requirements. In the event of a failure to set, it may cause a
circuit breaker fault on the main switchboard, adversely affecting the charging or
discharging of the battery.
Enter the Main Break Limit interface and then set the current limit according to
the utility's requirements.
