SolaX Power X3-IES Series User Manual

216
Technical Data
• Battery
Configuration List
No. Model BMS Battery Module
Nominal Energy
(kWh)
Operating
Voltage (Vdc)
1 T-BAT HS 5 TBMS-MCS0800E × 1 TP-HS50E × 1 5.1 90-116
2 T-BAT HS 10 TBMS-MCS0800E × 1 TP-HS50E × 2 10.2 180-232
3 T-BAT HS 15 TBMS-MCS0800E × 1 TP-HS50E × 3 15.3 270-348
4 T-BAT HS 20 TBMS-MCS0800E × 1 TP-HS50E × 4 20.4 360-464
5 T-BAT HS 25 TBMS-MCS0800E × 1 TP-HS50E × 5 25.6 450-580
6 T-BAT HS 30 TBMS-MCS0800E × 1 TP-HS50E × 6 30.7 540-696
Performance
Module
T-BAT HS 5
T-BAT HS
10
T-BAT HS
15
T-BAT HS
20
T-BAT HS
25
T-BAT HS
30
Nominal Voltage (Vdc)
102.4 204.8 307.2 409.6 512 614.4
Operating Voltage (Vdc)
90-116 180-232 270-348 360-464 450-580 540-696
Nominal Capacity (Ah) ¹
50 50 50 50 50 50
Nominal Energy (kWh) ¹
5.1 10.2 15.3 20.4 25.6 30.7
Usable Energy 90% DOD (kWh) ²
4.6 9.2 13.8 18.4 23.0 27.6
Max. Charge/Discharge Current (A)
³
50 50 50 50 50 50
Recommend Charge/Discharge
Current (A) ⁴
30 30 30 30 30 30
Standard Power (kW)
3 6.1 9.2 12.2 15.3 18.4
Max. Power (kW)
5.1 10.2 15.3 20.4 25.6 30.7
Short-circuit current
3.57kA (0.333 ms)
Battery Round-trip Efficiency (0.2 C,
25°C)
5
95%
Expected Lifetime (25°C) 10 years
Cycle Life 90% DOD (25°C) 6000 cycles
Charge Temperature
0°C ~ 53°C (Off heating function)³
-30°C ~ 53°C (In heating function)³
Discharge Temperature
-20°C ~ 53°C (Off heating function)³
-30°C ~ 53°C (In heating function)³
Storage Temperature 30°C ~ 50°C (6 months), -20°C ~ 30°C (12 months)
Ingress Protection IP66
Protection Class I
