35
Product Overview
System Diagram C (applicable to Australia)
Inverter
T-BAT-SYS
BAT+ BAT- BMS
PV1
PV2
COM
METER/CT
EPS
Grid
CT
RCD
Breaker
Breaker
N-BAR for EPS loads
N-BAR for loads
E-BAR
Main Breaker
Grid
Distribution box
Breaker
Loads
Loads
Dongle
PV
Figure 2-26 System diagram without X3-Matebox G2 for Australia
