52
Unpacking and Inspection
Items Quantity
Positive PV connectors & PV pin contacts
2 pairs for 4.0 ~ 6.0
kW inverter;
3 pairs for 8.0 ~ 15.0
kW inverter
Negative PV connectors & PV pin contacts
2 pairs for 4.0 ~ 6.0
kW inverter;
3 pairs for 8.0 ~ 15.0
kW inverter
Waterproof connector with RJ45 1 pc
M5*14 screws 6 pcs
M5*10 screws 2 pcs
Expansion tubes 2 pcs
Self-tapping screws 2 pcs
RJ45 terminals 3 pcs
RJ45 connector 1 pc
Document 1 pc
Cable shielding board 1 pc
6 mm
2
AC ferrules
10 pcs for all
inverters
4 mm
2
AC ferrules
1
10 pcs only for a 4.0
~ 8.0 kW inverter
Positioning cardboard 1 pc
Disassembling tool for PV terminal 1 pc
Dongle (optional) 1 pc
Note:
"
1
" means for a 4.0 ~ 8.0kW inverter, select suitable AC ferrules that match the diameter of
the Grid and EPS cables.
