B-1
APPENDIX B: Status Codes
Status Codes
Table B-1 lists the status codes and messages that can be produced by the InSight
®
X3
™
laser system. Most are self-explanatory and many errors can be corrected by the user.
In the event the error cannot be corrected or the action required to correct the error is not
known, contact your Spectra-Physics service representative. However, before you call,
write down the code and its description.
The READ:AHIS? command reports the most recent 16 codes from the system, with the
most recent code listed first. These codes along with a short description are also shown
on the LCD display on the front panel of the IPS-300 power supply, as shown in
Table B-1.
The status types shown in the table below are:
Status — System is functioning normally
Warning — System is functioning normally, but user action is suggested.
Fault — Laser diodes turn off and the shutter closes. User action is required.
Critical Fault—Laser turns off and cannot be restarted without cycling AC mains
power.
Table B-1 Status codes reported by the READ:AHIS? command
Status
Code
(line 2)
Type LCD Displays
(line 3 and line 4)
Description Action Required
0 Status Normal display No notices are displayed. No action is required.
56 Fault HW watchdog expired A hardware time-out has occurred. If the problem continues, contact
Spectra-Physics.
66 Fault SW watchdog expired A software time-out has occurred. Restore computer
communications.
Consider increasing the timeout
time using the Timer: Watchdog
command.
88 Fault Diode therm. shorted A diode laser thermistor short has
been detected.
Contact Spectra-Physics.
89 Fault Diode therm. open A diode laser thermistor open has
been detected.
Contact Spectra-Physics.
90 Fault Diode is too hot Diode laser temperature ≥ 35°C
(shutdown condition).
Check the coolant connections.
91 Warning Diode is warm Diode laser temperature ≥ 32°C
(shutdown condition).
Check the coolant connections.
