Safety Devices
Laser Safety and Compliance 2-5
Figure 2-6 Power supply safety devices
On/Off AC Power Switch
The power switch provides AC power to the control circuits. The switch glows amber
when AC power is supplied to the system.
Rear Panel
Front Panel
On/Off AC Power Switch
Display
I
O
Purge OutPower Control
DC Power
F1 F2
Purge Return
Fuses
AC Power InputPower Control
Connector
DC Power
Output to Laser Head
