1-4 Introduction
Specifications
The environmental conditions under which the laser system functions are listed below.
These specifications reflect indoor use conditions.
Table 1-2 Mechanical/electrical specifications
Feature
Specifications
English Units Metric Units
Size
InSight X3 Laser Head 19.76W x 35.83D x 7.25H in. 50.2W x 91.04D x 18.42H cm
IPS-300 Power Supply 19.0W x 17.9D × 6.9H in. 49.26W × 45.52D × 17.57H cm
ThermoRack 401 Chiller 19.0W x 20.0D × 6.9H in. 49.26W × 50.8D × 17.57H cm
Umbilical Length 10 ft. 3 m
Weight
InSight X3 Laser Head 185 lb. 84 kg
IPS-300 Power Supply 28 lb. 13 kg
ThermoRack 401 Chiller 49.5 lb. 22.5 kg
Power Requirements
IPS-300 Power Supply 100 – 120 V~/200 – 240 V~,
10 A/6 A max., 50/60 Hz
ThermoRack 401 Chiller 100 – 240 Vac, 9 A max.,
50/60 Hz
Table 1-3 Laser head environmental specifications
Feature Specification
Altitude Up to 2000 m
Temperature, operating 20°C to 25°C
Relative humidity, operating Maximum 75% noncondensing up to 25°C
Temperature, storage 15°C to 30°C
Relative humidity, storage <65% for 15°C to 35°C
Cooled water temperature in closed-loop chiller 21°C typical
1
1. Avoid obstructing the air exhaust grills which will result in the recirculation of hot exhaust air. Cooling air
enters through the front panel and exits through the rear fan apertures.
