Steketee EC-WEEDER - Page 34

1 1
2
2
3
3
5
47
6
4
Examples of Basic-Elements
1
1
2
2
3
3
4
4
5
6
7
The Basic-Element includes:
n Depth guiding wheel
1
with crank
2
for depth adjustment
n Tool holder for 3 tools
3
n Parallelogram
4
with lifting mechanism
5
n Fastening element for toolbar
– For square tube
6
– For prole tube
7
, here in heightened version for frame height
70 cm
The TRS-Element has the same design as the Basic-Element. The TRS-
Element includes:
1
2
3
5
6
7
4
n Depth guiding wheel
1
with crank
2
for depth adjustment
n Tool holder for 5 tools
3
n Stabilisation bar
4
n Parallelogram
5
with lifting mechanism
n Optional equipment: Spring
6
for more traction weight for ridge
tools
n Fastening element
7
for square tube toolbar
Basic-Element
TRS-Element
1
2
3
5
6
7
4
Design and description
