Parking position
1. Use your hand to lift the protection shield to above the height of
the lip
3
.
2.
Remove the peg
2
.
3.
Rotate the latch
1
downwards.
4. Insert the peg.
ð
The protection shield is held in this position.
Change installation position on the longitudinal rail
1.
Undo the fastening screws
2
of the two xing blocks.
2.
Push out the expansion bushes
3
.
3.
Move the xing blocks on the index bar
1
.
4. Tighten the fastening screws in the new position.
5. Screw the expansion bush back in.
Long protection shield
1
2
3
1
Latch
2
Peg
3
Lip
12
3
3
1
Index bar
2
Fastening screw
3
Expansion bush
3
