6 Parallel voice port D5
7 Parallel voice port D6
8 Parallel voice port D7, MSB
9 Common port 0V
10 Common port ＋24V
JP8
1 JP8.2 common port
2 Output HY5，light fan relay
DB1
Program burning record port
SW1
SW1.1 simultaneously turn on and CAN terminal
resistor is connected, simultaneously turn
off and terminal resistor disconnected
SW1.2
SW2
SW2.1 simultaneously turn on and enter into the
program recording status, simultaneously
turn off and return to normal running status
SW2.2
Note:
1) The JP 7 port of SM-02/H outputs eight-bit binary coding pulse signals, triggering voice
landing forecast during deceleration of car for stop, one second for every pulse output. The
eight-bit output is in the mode of transistors with open loop in the collector and shared anode,
output voltage DC24V, current capacity 50mA. The 8-bit binary coding provides as many as
255 output status in accordance with STEP WORD BANK for display, namely, supposing t that
user set B1 for the first floor display, the corresponding display code is 60. The JP7 output
signal is to transform the decimal bit of 60 into binary bit before outputting. The words” we
now arrive at B1 floor” are broadcasted by decoding that binary signal. At present 0-247 are
processed by the definition of the word bank for display（see the List of Display Codes in
6.5.10） whereas the codes of 248-255 are defined as following:
(248) 11111000: The elevator door close and the signal sent when the elevator is at
main landing and is about to move upward
(249) 11111001: the signal sent when elevator is in fire alarming status.
(250) 11111010: The signal appears when the door-closing position limit switch turns
from OFF to ON status during the door-opening.
(251) 11111011: The signal appears when the door-opening position limit switch
turns from OFF to ON status during the door-closing.
(252) 11111100： Overload alarming
(253) 11111101： Door opening in place and then forecast next moving direction as
upward
(254) 11111110：Door opening in place and then forecast next moving direction as
downward
(255) 11111111：To be defined.
2． Wiring and Connection
Car top controller and connection between power supply and communication bus
The car controller with power supply and CAN BUS is lined in from JP1, of which
JP1.01 and JP1.02 are for TXV+ and TXV-，JP1.03 and JP1.04 for TXA+ and TXA-
respectively. TXV+, TXV- are power input DC24V; TXA+ and TXA- are
communication lines which must be 4-wire Twisted Pairs.
Car top controller input signal connection
To Next Page
