STEP AS380-4T07P5 User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
143
Chapter 7 Parameter Table of Integrated Drive Controller
7.1 F Parameter List
Table 7.1 F Parameter List
No. Name Factory
Setup
Scope Unit Remarks
F00 Accelerating slope 0.550 0.200～
1.500
m/s
2
F01 Decelerating slope 0.550 0.200～
1.500
m/s
2
F02 S curve T0 (initial S
angle time T0)
1.300 0.300～
3.000
s
F03 S curve T1 (S angle T1 at
end of acceleration)
1.100 0.300～
3.000
s
F04 S curve T2 (S angle time
T2 at the beginning of
deceleration)
1.100 0.300～
3.000
s
F05 S curve T3 (S angle time
T3 at the end of
deceleration)
1.300 0.300～
3.000
s
F06 Nominal speed 1.750 0.100～
10.000
m/s
F09 Parking floor 1 1～64 ×
F10 Offset floor 0 0～64 ×
F11 Floor number 18 2～64 ×
F12 Inspection speed 0.250 0～0.630 m/s
F13 Creeping speed 0.060 0.010～
0.150
m/s
F14 Closing delay 1 (repsonse
to hall call)
3.0 0～30.0 s
F15 Closing delay 2 (repsonse
to car call)
3.0 0～30.0 s
F16 brake delay 0.2 0～2.0 s
F17 Automatic enable signal
release time
0.6 0.2～3.0 s
F18 Fire floor 1 1～64 ×
F20 Base station return delay
time
0 0～65535 s 0 represents not open;
other numbers
represents open and
delayed time.
F21 Leveling switch motion
delay distance (full-speed)
6 0～40 mm

STEP AS380-4T07P5 Specifications

General

Brand	STEP
Model	AS380-4T07P5
Category	Controller
Language	English
