Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
102
6.1.2 Car top control panel SM 02/H
Table 6.1 car top control panel SM.02/H plug-in specification
Table 6.2 Car top control panel SM.02/H input and output port definition
Port definition
Socket No Port No Definition Remark
JP1
1 24V red
2 GND yellow
3 CANH green
4 CANL blue
JP2
Connecting car top extension board
JP3
1 Out put JP3.2-JP3.3 common port
2 Output HY0，down arrival gong
3 Output HY1， upper arrival gong
4 Output 0V
5 Output 24V
JP4
1 Input JP4.2-JP4.3 common port
2 Input HX0，front door close in place Default NC
3 Input HX1，front door open in place Default NC
4 Output JP4.5-JP4.7common port
5 Output HY2，front door forced close output
6 Output HY3 ， front door close signal
output
7 Output HY4， front door open signal output
JP5
1 Input JP5.2-JP5.3 common port，0V
2 Input HX2，front door safety edge Default NC
3 Input HX3，front door light curtain Default NO
JP6
1 Input JP6.2-JP6.4 common port，0V
2 Input HX4，light load Default NO
3 Input HX5，full load Default NO
4 Input HX6，overload Default NC
JP7
1 Parallel voice port D0, LSB
2 Parallel voice port D1
3 Parallel voice port D2
4 Parallel voice port D3
5 Parallel voice port D4
Car top control panel SM-2/H plug-in specification
JP1
CH3.96-4A
JP5
5.08-3P-V-green
JP2
IDC-14P
JP6
5.08-4P-V-green
JP3
5.08-5P-V-绿
JP7
CH2510-10A
JP4 5.08-7P-V-绿
JP8
5.08-2P-V-green
