Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
26
◎ Don’t install it in the vicinity of sewage pipe or the
points with splatters
Or it may cause risk of property damage.
◎ Prevent screws, washers and metal rods falling into
the inside of elevator integrated drive controller
Or it may cause the risk of fire or property damage.
◎ Never start a elevator integrated drive controller
which is damaged or components are not completed
mounted
Or it may cause risk of property damage.
◎ Don’t install under direct sunlight
Or it may cause risk of overheat or resulting accidents;
2.4.1 Product installation location
The place where the elevator integrated drive controller will be installed shall meet such
conditions as:
a) Clean, without oil mist, dust or suspended matters which may fly into the fully enclosed
cabinet；
b) No possibility of metal powder, oil or water entering into the inside of elevator integrated
drive controller;
c) No timers and other combustibles are stored;
d) No radioactive substances are placed;
e) No hazardous gases or liquids are stored;
f) Vibration is as low as possible;
g) Not a salty atmosphere;
h) Not under direct sunlight;
i) Temperature rise is as low as possible;
when install the product in a enclosed cabinet, suitable cooling fans or air conditioners should be
provided to keep the ambient temperature under 40℃。
2.4.2 Product installation positioning and clearance requirements
To avoid impair the cooling effect of elevator integrated drive controller; this product shall be
installed at a well-ventilated place. In general, it is vertically installed with suitable clearances as
shown by Figure 2.2
