STEP AS380-4T07P5 User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
185
F182
Deceleration switch series
0
0～10
×
F183 Learn trip speed 0.800
0～1.000
m/s
F202
Motor type
0 0 / 1 ×
0: asychronous
1: synchronous
F203
Motor rated power According to
inverter
parameter
0．40～
160．00
KW
F204
Motor rated current According to
inverter
parameter
0．0～300．0
A
F205
Motor rated frequency
50.00
0.00～
120.00
Hz
F206
Motor rated rotary speed
1460
0～3000
rpm
F207
Motor rated voltage According to
inverter
parameter
0.～460
V
F208
Motor pole number
4
2～128
×
F209
Motor rated slip frequency
1.40
0～10.00
Hz
F210 Encoder type 0 0 / 1 / 2 ×
0:incremental Encode
r
1:SIN／COS Encoder
2: Endat Encoder
F211 Encoder pulse number 1024
500～16000
PPr
Note:
Before debugging, the basic parameters above must be correctly set; the basic parameters of
the motor can be input based on nameplate; according to the actual situation of the site, please
refer to Chapter VII for the parameter setting method and detailed definition.
8.4.2 Motor Parameter Self Study
No motor parameters self study for the synchronous motor. Because AS380 series elevator
integrated drive controller adopts the most advanced and unique drive technology which can
automatically obtain Encoder phase angle data, therefore, there is no need for motor auto-tuning
of Encoder phase angle.
Note that: every time AS380 series elevator integrated drive controller is used to control
synchronous motors, it will automatically capture Encoder information at its first running
after powered on, which takes 2 seconds or so. Therefore, the given running signal at this
