Instruction Manual for AS380 Series Elevator Integrated Drive Controller
106
3 Input HX9， rear door light curtain Default NO
4 Input power，need to connect switch power
supply+24V
JP4
1 Input HX10，rear door safety edge Default NO
2 Input HX11，backup
3 JP4.1-JP4.2 Input common port,0V
JP5
1 Input HX12，backup
2 JP5.1 Input common port,0V
6.3 Car controller panel SM.02/G introduction
6.3.1 Car controller panel SM02/G outside view and installation dimension
Fig 6.5 car controller outside view
