Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
65
4.7.2.5 the encoder signal tieline of sin/cos PG card
For the convenience of on-site wiring, the encoder signal tieline is provided for Sin/Cos PG card.
The tieline will turn encoder signal into D-type 15 pin plug through connection. The detailed
definition is as follows:
M3螺母
M3螺母
屏蔽层焊于DB插头的铁壳上
310
C1
塑壳2*7
C2
DB15母头
PIN3
PIN4
PIN5
PIN6
PIN7
PIN8
PIN9
PIN 10
PIN 11
PIN 12 PIN 11
PIN 10
PIN 12
PIN 13
PIN 5
PIN 6
PIN 8
PIN 1
PIN 3
PIN 4
PIN 13
PIN 14 PIN 9
PIN 7
25
对应颜色
信号
红
红/白
橙
黄/黑
橙/黑
绿
绿/黑
黑
黑/白
黄
蓝/黑
蓝
cos-
cos+
sin-
sin+
D-
D+
C-
C+
GND
v+
R-
R+
Fig 4.23 Sin/Cos PG tieline definition
4.7.3 ABZ incremental 5V PG card
ABZ incremental 5V PG card (model AS.T041) can receive three kind of encoder output signal,
which mean encoder of open collector signal or push-pull signal or differential signal can be
installed.
4.7.3.1 ABZ incremental 5V PG card terminal layout
ABZ incremental 5V PG card (model AS.T041) terminal layout see fig 4.23
Fig 4.23 ABZ incremental 5V PG card terminal layout
