STEP AS380-4T07P5 User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
18
Chapter two: Model and Specification
This chapter introduces the model, specification, and installation dimension of AS380 series
integrated drive controller.
2.1 Model of integrated drive controller
Table 2.1 is the model list of AS380 series integrated drive controller.
Table 2.1 AS380 series integrated drive controller model list
model
AS380-
Rated capacity
（kVA）
Rated output
current（A）
Matching Motor
（kW）
2S01P1 2.3 6.0 1.1
2S02P2 4.6 12 2.2
2S03P7 6.9 18 3.7
4T02P2 4.7 6.2 2.2
4T03P7 6.9 9 3.7
4T05P5 8.5 13 5.5
4T07P5 14 18 7.5
4T0011 18 27 11
4T0015 24 34 15
4T18P5 29 41 18.5
4T0022 34 48 22
4T0030 50 65 30
4T0037 61 80 37
4T0045 74 97 45
4T0055 98 128 55
4T0075 130 165 75
2.2 The technical specification of integrated drive controller
Table 2.2 is the technical specification of AS380 series integrated drive controller.

STEP AS380-4T07P5 Specifications

General

Brand	STEP
Model	AS380-4T07P5
Category	Controller
Language	English
