Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
60
8 Rear door open 9 Rear door close
10 Not stop at door-zone 11 Fault
12 Run 13 Emergency Level state output
Note：
1、 Input and output functional description can be set by the program ， same function cannot be
set at two ports
2、 COM is the COM on the main board
4.6.5 Notice items for control circuit terminal wiring
The wire of control terminal should be arranged far away from the main circuit wire. Otherwise,
false operation may occur as the result of the interference.
4.7 the wires of PG card terminal
PG card has 4 types to adapt to different kinds of encoder. See the below table
PG card type Motor type model Input signal remarks
ABZ
incremental
12V
Asynchronous/synchronous AS.T025
Collector open
circuit signal、
push-pull signal
Encoder
voltage 12V
SIN/COS
type
synchronous AS.T024
SIN/COS
differential signal
ABZ
incremental
5V
Asynchronous/synchronous AS.T041
Collector open
circuit signal,
push-pull signal,
differential signal
Encoder
voltage 5V
Endat
absolute
value
synchronous AS.L06/L
Endat output signal
4.7.1 ABZ incremental 12v PG card
ABZ incremental 12v PG card (model AS.T025) can receive the output signal of tow types of
encoder with the installation of encoders of collector open circuit signal and push-pull signal
4.7.1.1 ABZ incremental 12v PG card terminal layout
Please see fig 4.18 for the ABZ incremental 12v PG card （model AS.T025）terminal layout
