Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
55
JP1.4 X22
Hall door lock circuit inspection
positive voltage port110V/220V input
Input
JP1.5 XCOM
X20-X22 input signal common port 0V,
internally connected to JP1.1
JP2
JP2.1 Y0 Band brake contactor output Output
JP2.2 Y1 Band brake strong contactor output Output
JP2.3 Y2 Main contactor output Output
JP2.4 COM1 Output relay Y0-Y3 common port
JP3
JP3.1 Y3 Door pre-opening relay Output
JP3.2 Y4
blackout emergency stop leveling
completion signal output
Output
JP3.3 COM2 output relay Y3-Y4 common port
JP3.4 Y5 firefighting signal output Output
JP3.5 COM3 output relay Y5 common port
JP3.6 Y6 reserved ,standby Output
JP3.7 COM4 output relay Y6 common port
JP4
JP4.1 0V 0V DC
JP4.2 CAN0H
instruction serial communication signal
portTXA0+
JP4.3 CAN0L
instruction serial communication signal
portTXA0-
JP5
JP5.1 0V 0V DC
JP5.2 CAN1H
parallel connection serial communication
signal portTXA1+
JP5.3 CAN1L
parallel connection serial communication
signal portTXA1-
JP6
JP6.1 0V quarantine OV DC
JP6.2
CAN2H Community monitoring TXA2+
JP6.3
CAN2L Community monitoringTXA2-
JP7
JP7.1
G5VIO Isolating power 0V
JP7.2
+5VIO Isolating power +5V
JP7.3
Empty slotTBD
JP7.4
G24VIO opt coupler input shield power 0V
JP7.5
+24VIO opt coupler input shield power +24V
