Instruction Manual for AS380 Series Elevator Integrated Drive Controller
241
Appendix B Function Parameter, Fault List Summary
This appendix summarize the function parameter, running situation and fault list, in order
to make it convenient for the user to check and use.
B.1 Function Parameter List
No. Name Factory
Setup
Scope Unit Remarks
F00 Accelerating slope 0.550 0.200～
1.500
m/s
2
F01 Decelerating slope 0.550 0.200～
1.500
m/s
2
F02 S curve T0 (initial S
angle time T0)
1.300 0.300～
3.000
s
F03 S curve T1 (S angle T1 at
end of acceleration)
1.100 0.300～
3.000
s
F04 S curve T2 (S angle time
T2 at the beginning of
deceleration)
1.100 0.300～
3.000
s
F05 S curve T3 (S angle time
T3 at the end of
deceleration)
1.300 0.300～
3.000
s
F06 Nominal speed 1.750 0.100～
10.000
m/s
F09 Parking floor 1 1～64 ×
F10 Offset floor 0 0～64 ×
F11 Floor number 18 2～64 ×
F12 Inspection speed 0.250 0～0.630 m/s
F13 Creeping speed 0.060 0.010～
0.150
m/s
F14 Closing delay 1 (repsonse
to hall call)
3.0 0～30.0 s
F15 Closing delay 2 (repsonse
to car call)
3.0 0～30.0 s
F16 brake delay 0.2 0～2.0 s
F17 Automatic enable signal
release time
0.6 0.2～3.0 s
F18 Fire floor 1 1～64 ×
F20 Base station return delay
time
0 0～65535 s 0 represents not open;
other numbers
represents open and
delayed time.
F21 Leveling switch motion
delay distance (full-speed)
6 0～40 mm
