Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
110
6.4.1 Instruction control board SM-03 outside view and installation dimension
Fig 6.8 instruction control board outside view
4- 葫芦孔
Fig 6.9 instruction controller board installation dimension
6.4.2 Instruction controller board SM-03 plug-in and port definition introduction
Table 6.7 instruction control board plug-in specification
Table 6.8 instruction control board port definition
Instruction controller board
Socket No Model
JP1/JP2/JP3/JP4/JP5/JP6/JP7/JP8
CH2510-4
JP9/JP10
14 pin parallel dot-matrix socket
