STEP AS380-4T07P5 User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
118
☆ Terminal Definition and Plug-in Specification on SM-04-UL
Serial Descriptions Remarks
JP8
Serial port, of which Pin 1 for TXV+, Pin 2 for TXV-, Pin 3 for TXA+ and Pin 4 for
TXA- respectively.
CH3.96-4
JP11
Down-call terminals, of which Pin 1 -and Pin 2 + for button indicator, Pin 3 and Pin 4
for button input.
CH2510-4
JP12
Up-call terminals, of which Pin 1- and Pin 2+ for button indicator, Pin 3 and Pin 4 for
button input.
CH2510-4
JP10
Pin 3 and Pin 4 for the input of normal open contact of the lockout switch, Pin 1 and
Pin 2 for stand-by.
CH2510-5
SW1
Resistor jumper for serial communication terminals for connecting the 120Ω built-in
resistor when jumpers are put on together. Both ON for connection of CAN terminal
resistor, both OFF for disconnection of it.
SW2
SW2.1 ON for setting number of passengers allowed boarding in car by pressing on
up and down buttons, OFF for normal. SW2.2 ON for display in English, OFF for
display in Chinese.
SW5
SW5.1 ON for setting address codes by pressing on up and down buttons, OFF for
normal. SW5.2 ON for selecting time options by pressing on up button, for changing
in time by pressing on down button, OFF for normal. Both SW2.1 and SW5.1 ON
before power-on for adjusting display contrast by pressing on up and down buttons.
List 6.14 Terminal Definitions and Specification of SM-04-UL
Table 6-15 function description
Address Codes
SW5.1 ON, press on up and down call buttons. Range of Codes 0 to 48
Time Setting
SW5.2 ON, press on up call button to select time options, press on down call button to
make changes in time.
Passengers Allowed
for Entry in Car
SW2.1 ON, press on up and down call buttons to set the number of passengers allowed
boarding in car.
Display Contrast
Adjustment
in hardware Adjust the value of resistance in R53 by turning a screwdriver while
watching the change in contrast. It allows for a wide range in adjustment.
in software Set both SW2.1 and SW5.1 ON before switch on power and adjust the
display contrast by pressing on up and down call buttons, only good for fine
adjustment.
Language Setting
SW2.2 ON for display in English, OFF for display in Chinese.
6.5.5 Car Call & LCD Control Board SM-04-VL
☆ Outside View & Mounting Dimensions of Landing call display Board SM-04-VL16/A
