Instruction Manual for AS380 Series Elevator Integrated Drive Controller
66
4.7.3.2 ABZ incremental 5V PG card terminal label
ABZ incremental 5V PG card terminal label as follow:
JP3 frequency-dividing output terminal
V0 FB V0
JP2 input terminal
A+ A- B+ B- Z+ Z- V+ V- PE
4.7.3.3 ABZ incremental 5V PG card terminal function description
ABZ incremental 5V PG card terminal function description see table 4.8
Table 4.8 ABZ incremental 5V PG card terminal function description
name Pin No
Terminal
label
Terminal
function
description
specification
Frequenc
y-dividin
g signal
output
JP3.1 FA
Frequency-divid
ing signal output
A phase
Triode collective open output （ max output
frequency 100kHz）；
JP3.2 0V 24V GND
JP3.3 FB
Frequency-divid
ing signal output
B phase
JP3.4 0V 24V GND
Encoder
input
JP2.1 A+
Encoder A phase
signal +
Open collector/push-pull ， max input frequency
100kHz
JP2.2 A-
Encoder A phase
signal -
JP2.3 B+
Encoder B phase
signal +
JP2.4 B-
Encoder B phase
signal -
JP2.5 Z+
Encoder Z phase
signal +
JP2.6 Z-
Encoder Z phase
signal -
