Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
134
6.6.7.4 Input and Output Interface Definition
The Definition of PortJP2
Pin Port Name
JP2-1 Void
JP2-2 TXA4- Communication signal negative terminal of elevator No.4 in the group control system
JP2-3 TXA4+ Communication signal positive terminal of elevator No.4 in the group control system
JP2-4 TXV4- Power supply negative terminal of elevator No.4 in the group control system
JP2-5 TXV4+ Power supply positive terminal of elevator No.4 in the group control system
JP2-6 Void
JP2-7 TXA3- Communication signal negative terminal of elevator No.3 in the group control system
JP2-8 TXA3+ Communication signal positive terminal of elevator No.3 in the group control system
JP2-9 TXV3- Power supply negative terminal of elevator No.3 in the group control system
JP2-10 TXV3+ Power supply positive terminal of elevator No.3 in the group control system
JP2-11 void
JP2-12 TXA2- Communication signal negative terminal of elevator No.2 in the group control system
JP2-13 TXA2+ Communication signal positive terminal of elevator No.2 in the group control system
JP2-14 TXV2- Power supply negative terminal of elevator No.2 in the group control system
JP2-15 TXV2+ Power supply positive terminal of elevator No.2 in the group control system
JP2-16 Void
JP2-17 TXA1- Communication signal negative terminal of elevator No.1 in the group control system
JP2-18 TXA1+ Communication signal positive terminal of elevator No.1 in the group control system
JP2-19 TXV1- Power supply negative terminal of elevator No.1 in the group control system
JP2-20 TXV1+ Power supply positive terminal of elevator No.1 in the group control system
Definition of Port JP3
Pin Port Name
JP3-1 Void
JP3-2 TXA4- Communication signal negative terminal of elevator No.8 in the group control system
JP3-3 TXA4+ Communication signal positive terminal of elevator No.8 in the group control system
JP3-4 TXV4- Power supply negative terminal of elevator No.8 in the group control system
JP3-5 TXV4+ Power supply positive terminal of elevator No.8 in the group control system
JP3-6 Void
JP3-7 TXA3- Communication signal negative terminal of elevator No.7 in the group control system
JP3-8 TXA3+ Communication signal positive terminal of elevator No.7 in the group control system
JP3-9 TXV3- Power supply negative terminal of elevator No.7 in the group control system
JP3-10 TXV3+ Power supply positive terminal of elevator No.7 in the group control system
JP3-11 Void
JP3-12 TXA2- Communication signal negative terminal of elevator No.6 in the group control system
JP3-13 TXA2+ Communication signal positive terminal of elevator No.6 in the group control system
JP3-14 TXV2- Power supply negative terminal of elevator No.6 in the group control system
JP3-15 TXV2+ Power supply positive terminal of elevator No.6 in the group control system
JP3-16 Void
JP3-17 TXA1- Communication signal negative terminal of elevator No.5 in the group control system
JP3-18 TXA1+ Communication signal positive terminal of elevator No.5 in the group control system
